SPRS645F – AUGUST 2010 – REVISED OCTOBER 2013
5.7.1.3
Reset Pin (RESET)
The device can receive an external reset signal on the RESET pin. As specified above in Section 5.7.1.2 ,
Main Power-On Reset , the RESET pin is combined with the internal POWERGOOD signal, that is
generated by the MAIN POR, via an AND-gate. The output of the AND gate provides the hardware reset
to the chip. The RESET pin may be tied high and the MAIN POR can provide the hardware reset in case
DSP_LDO is enabled (DSP_LDO_EN = 0), but an external hardware reset must be provided via the
RESET pin when the DSP_LDO is disabled (DSP_LDO_EN = 1).
Once the hardware reset is applied, the system clock generator is enabled and the DSP starts the boot
sequence. For more information on the boot sequence, see Section 3.4 , Boot Sequence .
5.7.2
Pin Behavior at Reset
During normal operation, pins are controlled by the respective peripheral selected in the External Bus
Selection Register (EBSR) register. During power-on reset and reset, the behavior of the output pins
changes and is categorized as follows:
?
?
?
?
?
?
?
?
High Group: EM_CS4, EM_CS5, EM_CS2, EM_CS3, EM_DQM0, EM_DQM1, EM_OE, EM_WE,
LCD_RS/SPI_CS3, EM_SDCAS, EM_SDRAS
Low Group: LCD_EN_RDB/SPI_CLK, EM_R/W, MMC0_CLK/I2S0_CLK/GP[0],
MMC1_CLK/I2S1_CLK/GP[6], EM_SDCLK
Z Group: EM_D[15:0], EMU[1:0], SCL, SDA, LCD_D[0]/SPI_RX, LCD_D[1]/SPI_TX,
LCD_D[10]/I2S2_RX/GP[20]/SPI_RX, LCD_D[11]/I2S2_DX/GP[27]/SPI_TX,
LCD_D[12]/I2S2_RTS/GP[28]/I2S3_CLK, LCD_D[13]/I2S2_CTS/GP[29]/I2S3_RS,
LCD_D[14]/I2S2_RXD/GP[30]/I2S3_RX, LCD_D[15]/I2S2_TXD/GP[31]/I2S3_DX, LCD_D[2]/GP[12],
LCD_D[3]/GP[13], LCD_D[4]/GP[14], LCD_D[5]/GP[15], LCD_D[6]/GP[16], LCD_D[7]/GP[17],
LCD_D[8]/I2S2_CLK/GP[18]/SPI_CLK,LCD_D[9]/I2S2_FS/GP[19]/SPI_CS0, RTC_CLKOUT,
MMC0_CMD/I2S0_FS/GP[1], MMC0_D0/I2S0_DX/GP[2], MMC0_D1/I2S0_RX/GP[3],
MMC0_D2/GP[4], MMC0_D3/GP[5], MMC1_CMD/I2S1_FS/GP[7], MMC1_D0/2S1_DX/GP[8],
MMC1_D1/I2S1_RX/GP[9], MMC1_D2/GP[10], MMC1_D3/GP[11], TDO, WAKEUP
CLKOUT Group: CLKOUT, LCD_CS1_E1/SPI_CS1
SYNCH 0 → 1 Group: LCD_CS0_E0/SPI_CS0, LCD_RW_WRB/SPI_CS2, EM_SDCKE
SYNCH 1 → 0 Group: EM_CS0, EM_CS1
SYNCH X → 1 Group: EM_BA[1:0], XF
SYNCH X → 0 Group: EM_A[20:0]
84
Peripheral Information and Electrical Specifications
Product Folder Links: TMS320C5515
Copyright ? 2010–2013, Texas Instruments Incorporated
